1G SFP ZX/ZR

Vitex Part #: VS-01ZR1CS-AA

The VS-01ZR1CS-AA is a 1.25Gbps SFP ZR transceiver designed for long-distance single-mode fiber (SMF) communication up to 80km. It operates at 1550nm using a DFB laser transmitter and PIN-TIA receiver, features a duplex LC connector, and is hot-pluggable. It supports standard commercial operating temperatures (0 to 70°C) and uses a single 3.3V power supply.

Features
Specifications
Applications
FAQs
Datasheet

0 to 70°C operating case temperature SFP package with duplex LC Receptacle connector
Hot-pluggable capability
Single 3.3V power supply 1550nm DFB Laser Transmitter and High performance PIN-TIA Receiver Data links up to 1.25Gbps
Up to 80km transmission distance with SMF Low power dissipation
Digital diagnostic monitor interface Low EMI and excellent ESD protection Class I laser safety standard IEC-60825 compliant RoHS 6 compliance

Form Factor	SFP
Data Rate	1G
Wavelength	1550nm
Distance	80km
Connector	LC Duplex
Protocol	Ethernet
Temperature	Commercial (0–70°C)

Enterprise Networking Storage Area Networks (SAN)

Q: What is the 1G SFP ZX/ZR?
A: It is a 1G optical transceiver in the SFP form factor, supporting Ethernet with a reach of 80km over Single-Mode Fiber (SMF).

Q: What is the maximum transmission distance?
A: This transceiver supports up to 80km over Single-Mode Fiber (SMF) at 1550nm.

Q: What connector type does this use?
A: It uses a LC Duplex connector with Single-Mode Fiber (SMF).

Q: What applications is this designed for?
A: It is designed for Enterprise Networking, Storage Area Networks (SAN).

Q: Is this module compatible with my switch or router?
A: This transceiver is SFP MSA compliant, meaning it is designed to work with any platform that supports the SFP standard. Contact Vitex engineering to confirm compatibility with your specific hardware.

Technical Documentation

Access comprehensive technical specifications, mechanical diagrams, and validation reports.

Download Datasheet PDF
