1G SFP SX/SR

Vitex Part #: VS-01SR1CS-AA

The VS-01SR1CS-AA is an SFP Gigabit Ethernet transceiver featuring Class I laser safety compliance, an operating temperature range of 0 to 70°C, and a single 3.3V power supply. It supports distances up to 550m on 50/125Î¼m multimode fiber, with an operational data rate of up to 1.25Gb/s. The device is packaged in an SFP form factor with an LC receptacle connector, offers hot-pluggable capability, and utilizes an 850nm VCSEL-based transmitter.

Features
Specifications
Applications
FAQs
Datasheet

0 to 70°C operating case temperature
Single 3.3V power supply
Up to 550m on 50/125Î¼m MMF Operation data rate: up to 1.25Gb/s SFP package with LC Receptacle connector
Hot-pluggable capability 850nm VCSEL-based transmitter LVPECL compatible data input/output interface
Low power dissipation Low EMI and excellent ESD protection
Digital diagnostic monitor interface Class I laser product, RoHS compliance

Form Factor	SFP
Data Rate	1G
Wavelength	850nm
Distance	500m
Connector	LC Duplex
Protocol	Ethernet
Temperature	Commercial (0–70°C)

Enterprise Networking Storage Area Networks (SAN)

Q: What is the 1G SFP SX/SR?
A: It is a 1G optical transceiver in the SFP form factor, supporting Ethernet with a reach of 500m over Multi-Mode Fiber (MMF).

Q: What is the maximum transmission distance?
A: This transceiver supports up to 500m over Multi-Mode Fiber (MMF) at 850nm.

Q: What connector type does this use?
A: It uses a LC Duplex connector with Multi-Mode Fiber (MMF).

Q: What applications is this designed for?
A: It is designed for Enterprise Networking, Storage Area Networks (SAN).

Q: Is this module compatible with my switch or router?
A: This transceiver is SFP MSA compliant, meaning it is designed to work with any platform that supports the SFP standard. Contact Vitex engineering to confirm compatibility with your specific hardware.

Technical Documentation

Access comprehensive technical specifications, mechanical diagrams, and validation reports.

Download Datasheet PDF
