1G SFP LX/LR

Vitex Part #: VS-01LR1CS-AA

Vitex VS-01LR1CS-AA is equipped with an LC Receptacle connector, offers seamless hot-pluggable integration and operates on a single 3.3V power supply. Utilizing a 1310 FP laser and PIN photodiode, it facilitates reliable 10km transmission over single-mode fiber (SMF). Designed with an LVPECL-compatible data input/output interface, this module ensures low power dissipation, minimized electromagnetic interference (EMI), and robust electrostatic discharge (ESD) protection. As a Class I laser product, it adheres to stringent safety standard.

Features
Specifications
Applications
FAQs
Datasheet

0 to 70°C operating case temperature SFP package with LC Receptacle connector
Hot-pluggable capability
Single 3.3V power supply 1310 FP laser and PIN photodiode 10km transmission distance with SMF LVPECL compatible data input/output interface
Low power dissipation Low EMI and excellent ESD protection Class I laser product
RoHS compliance for SO013366-PLGA

Form Factor	SFP
Data Rate	1G
Wavelength	1310nm
Distance	10km
Connector	LC Duplex
Protocol	Ethernet
Temperature	Commercial (0–70°C)

Enterprise Networking Storage Area Networks (SAN)

Q: What is the 1G SFP LX/LR?
A: It is a 1G optical transceiver in the SFP form factor, supporting Ethernet with a reach of 10km over Single-Mode Fiber (SMF).

Q: What is the maximum transmission distance?
A: This transceiver supports up to 10km over Single-Mode Fiber (SMF) at 1310nm.

Q: What connector type does this use?
A: It uses a LC Duplex connector with Single-Mode Fiber (SMF).

Q: What applications is this designed for?
A: It is designed for Enterprise Networking, Storage Area Networks (SAN).

Q: Is this module compatible with my switch or router?
A: This transceiver is SFP MSA compliant, meaning it is designed to work with any platform that supports the SFP standard. Contact Vitex engineering to confirm compatibility with your specific hardware.

Technical Documentation

Access comprehensive technical specifications, mechanical diagrams, and validation reports.

Download Datasheet PDF
