1G SFP EX/ER

Vitex Part #: VS-01ER1CS-AA

Vitex VS-01ER1CS-AA offers seamless hot-pluggable integration and operates on a single 3.3V power supply. It facilitates reliable 40km transmission over single-mode fiber (SMF). The module ensures low power dissipation, minimized electromagnetic interference (EMI), and robust electrostatic discharge (ESD) protection. It adheres to SFP MSA and IEEE Std 802.3ah standards and operates at Commercial temperature grade (0-70°C).

Features
Specifications
Applications
FAQs
Datasheet

SFP package with duplex LC Receptacle connector
Supports up to 1.25Gb/s bit rates 1310nm DFB transmitter and PIN-TIA receiver
Commercial operating case temperature: 0 to 70°C
Up to 40km distance with SMF
Hot-pluggable capability
Single 3.3V power supply Built-in Digital Diagnostic monitoring (DDM) function Low EMI and excellent ESD protection Class I laser safety standard IEC-60825 compliant RoHS-6 compliance
Complies with SFP MSA
Complies with IEEE Std 802.3ah
Complies with SFF-8472
Complies with FCC 47 CFR Part 15, Class B
Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007

Form Factor	SFP
Data Rate	1G
Wavelength	1310nm
Distance	40km
Connector	LC Duplex
Protocol	Ethernet
Temperature	Commercial (0–70°C)

Enterprise Networking Storage Area Networks (SAN)

Q: What is the 1G SFP EX/ER?
A: It is a 1G optical transceiver in the SFP form factor, supporting Ethernet with a reach of 40km over Single-Mode Fiber (SMF).

Q: What is the maximum transmission distance?
A: This transceiver supports up to 40km over Single-Mode Fiber (SMF) at 1310nm.

Q: What connector type does this use?
A: It uses a LC Duplex connector with Single-Mode Fiber (SMF).

Q: What applications is this designed for?
A: It is designed for Enterprise Networking, Storage Area Networks (SAN).

Q: Is this module compatible with my switch or router?
A: This transceiver is SFP MSA compliant, meaning it is designed to work with any platform that supports the SFP standard. Contact Vitex engineering to confirm compatibility with your specific hardware.
