10G SFP+ ZR DWDM 80km
Vitex's VS-10ZR1CDxx-AA is a 10G SFP+ ZR DWDM transceiver designed for long-reach applications, supporting bit rates from 9.95Gb/s to 11.1Gb/s and achieving a maximum link length of 80km. It operates on a 3.3V power supply and features a duplex LC connector within an SFP+ package, using a temperature-stabilized 1550nm DWDM EML transmitter and a high-performance APD receiver.
Fixed-wavelength operation on the ITU-T 100GHz grid, C-band channels 12 to 61 (1528.8nm to 1568.0nm). Commercial temperature grade, 0°C to +70°C. For the industrial grade (-40°C to +85°C), see VS-10ZR1IDxx-AA.
Request a quote
- Features
- Specifications
- Applications
- FAQs
- Datasheet
- Supports 9.95Gb/s to 11.1Gb/s bit rates
- Maximum link length of 80km over G.652 single-mode fiber
- Fixed-wavelength DWDM on the ITU-T 100GHz grid, C-band channels 12–61 (1528.8–1568.0nm)
- Temperature-stabilized 1550nm DWDM EML transmitter with high-performance APD receiver
- SFP+ package with duplex LC connector
- Single 3.3V power supply, power consumption < 2W
- Built-in CDR and digital diagnostic monitoring (DDM)
- SFI electrical interface
- Commercial operating case temperature: 0°C to +70°C
- Complies with IEEE 802.3ae, SFF-8431, SFF-8472, FCC 47 CFR Part 15 Class B
- RoHS-10 compliant
| Category | Optical Transceivers |
|---|---|
| Form Factor | SFP+ |
| Data Rate | 10G (9.95–11.1 Gb/s) |
| Wavelength | DWDM C-band, ITU-T 100GHz grid, channels 12–61 (1528.8–1568.0nm) |
| Distance | 80km |
| Fiber | Single-Mode Fiber (SMF) |
| Connector | LC Duplex |
| Transmitter | Temperature-stabilized 1550nm DWDM EML |
| Receiver | APD |
| Average Launch Power | 0 to +4 dBm |
| Receiver Sensitivity | ≤ -24 dBm |
| Receiver Overload | ≥ -7 dBm |
| Power Supply | 3.3V, < 2W |
| Protocol | Ethernet |
| Temperature | Commercial (0–70°C) |
| Standards | IEEE 802.3ae, SFF-8431, SFF-8472 |
Q: What is the 10G SFP+ ZR DWDM 80km?
A: It is a 10G fixed-wavelength DWDM optical transceiver in the SFP+ form factor, supporting Ethernet with a reach of 80km over Single-Mode Fiber (SMF).
Q: Which DWDM channels are available?
A: ITU-T 100GHz grid C-band channels 12 through 61, covering 1528.8nm to 1568.0nm. Specify the channel number in place of "xx" in the part number when ordering.
Q: Do you offer an industrial temperature version?
A: Yes. This page covers the commercial grade (VS-10ZR1CDxx-AA, 0°C to +70°C). The industrial grade is VS-10ZR1IDxx-AA, rated -40°C to +85°C, listed separately.
Q: Is this a BiDi module?
A: No. This is a two-fiber DWDM module with a duplex LC connector — one fiber for transmit, one for receive. If you need single-fiber bidirectional operation, see the Vitex BiDi transceiver range.
Q: Is this module compatible with my switch or router?
A: This transceiver is SFP+ MSA compliant, meaning it is designed to work with any platform that supports the SFP+ standard. Contact Vitex engineering to confirm compatibility with your specific hardware.
