10G SFP+ eER BiDi 60km 1330nm / 1270nm

Vitex Part #: VS-10060CB2-AA

The VS-10060CB2-AA is a 10G BiDi SFP+ transceiver engineered for extended-reach optical connectivity across single-mode fiber (SMF) up to 60 kilometers. This transceiver supports data rates reaching 10.7Gb/s and is designed for robust performance in extreme environments, with an operational temperature range of 0 to 70°C. Featuring a single LC connector within a hot-pluggable SFP+ form factor, it simplifies deployment and maintenance. The module utilizes a 1330nm DFB transmitter and a 1270nm APD receiver.

Features
Specifications
Applications
FAQs
Datasheet

Supports up to 10.7Gb/s bit rates 0 to 70°C operating case temperature SFP+ package with single LC receptacle connector
Hot-pluggable capability
Single 3.3V power supply 1330nm DFB transmitter and 1270nm APD receiver
Up to 20dB power budget over SMF
Low power dissipation SFI electrical interface Low EMI and excellent ESD protection Built- in Digital Diagnostic Monitoring (DDM) function Class I laser safety standard IEC-60825 compliant, RoHS-6 compliance

Form Factor	SFP+
Data Rate	10G
Wavelength	BiDi
Distance	40km
Connector	LC Simplex
Protocol	Ethernet
Temperature	Commercial (0–70°C)

5G Fronthaul & Midhaul CPRI & eCPRI Mobile Backhaul

Q: What is the 10G SFP+ eER BiDi 60km 1330nm / 1270nm?
A: It is a 10G optical transceiver in the SFP+ form factor, supporting Ethernet with a reach of 40km over fiber optic cable.

Q: What is the maximum transmission distance?
A: This transceiver supports up to 40km over fiber optic cable at BiDi.

Q: What connector type does this use?
A: It uses a LC Simplex connector with fiber optic cable.

Q: What applications is this designed for?
A: It is designed for 5G Fronthaul & Midhaul, CPRI & eCPRI, Mobile Backhaul.

Q: Is this module compatible with my switch or router?
A: This transceiver is SFP+ MSA compliant, meaning it is designed to work with any platform that supports the SFP+ standard. Contact Vitex engineering to confirm compatibility with your specific hardware.

Technical Documentation

Access comprehensive technical specifications, mechanical diagrams, and validation reports.

Download Datasheet PDF
